Product Details
BRTIRPZ1508A is a four-axis robot for monotonous, frequent, and repetitive long-term operations, or operations in dangerous and harsh environments. The actual palletizing height can reach 1.8m, with a 2000mm arm span and a maximum load of 65kg. It has a large space coverage range (can fully cover all sizes of pallets up to 1.2m * 1.2m). The flexibility of multiple degrees of freedom makes the structure more streamlined and easy to maintain. It can handle scenarios such as loading and unloading, handling, unpacking and feeding, unpacking and stacking with ease. High precision, repeated positioning accuracy: ± 0.15mm
Main Specification
Arm Span(mm): 2000
Repeatability(mm): ±0.15
Max Payload(kg): 65
Power Supply(kVA): 7.8
Boday Weight(kg): ~618
Item | Range | Max.speed | |
Arm | J1 | 1800mm | 600mm/s |
J2 | ±170° | 117°/s | |
J3 | ±145° | 171°/s | |
Wrist | J4 | ±360° | 296°/s |
